CL259 Racing Fine Line (Port) - SILVER

Previous Product | Next Product
Product Description

The tooth design of the CL259 Racing Fine Line (Port) allows a quick, positive lock that is easy to release. Add this to its low profile and ability to hold high loads, makes it an ideal cleat for adjusting leech lines on larger sails. Use a backplate when riveting a cleat onto fabric to prevent the rivet pulling through. It can be mounted in two positions and can be sewn or riveted to the sail.  The CL259 is usually ftted to the Starboard side of a sail, when used for tensioning leech lines. See the fitting diagrams above.

Also used for industrial sun blinds and as a low profile deck cleat.

.

Technical Details   Metric Imperial
Rope Diameter 3 - 6mm 1/8 - 1/4"
Material Aluminium Aluminium
Hole Centres 49mm 1 15/16"
Length 70mm 2 3/4"
Width 21mm 13/16"
Height 14mm 9/16"
Bolt Size M4 #8-32. 5/32"
Screw Size 4.2mm No 8
Weight 19gms 0.7oz
